12V LED Stainless Steel Flat Head Button 12mm

1.Ultra short length , only 12mm.2.Optional connector,To ensure contact performance,reduce waste of labor;3.With both flat and spherical design,operation is more convenient;4.With super metal texture and high-end of appearance design,improve the ability to resist welding deformation;5.Waterproof and dustproof grade up to IP

Featured Products

1.Ultra short length , only 12mm.
2.Optional connector,To ensure contact performance,reduce waste of labor;
3.With both flat and spherical design,operation is more convenient;
4.With super metal texture and high-end of appearance design,improve the ability to resist welding deformation;
5.Waterproof and dustproof grade up to IP65;
6.Mechanical life: up to 600,000times,it can work at -20ºC~+55ºC;
7.It has applied of many patents ,RoHS,CE approved;


Product NamePush Button Switch
OriginZhejiang China

ModelB-12K
Mounting Hole12mm
Terminal4-5
Operation Type Self-locking & reset
Light TypeWith Light & Without Light
Light ColorRed\ Yellow \Blue
Housing Color Blue
Input voltage range (3V ~ 6V) \ 12V ~ 24V
 Current range3A 5A 10A
Switch Combination1NO 1NC
Head TypeFlat
Protection LevelIP65\IP67
Terminal type4~5 Pin Terminals
MaterialNickel plated brass\stainless steel

Delivery Days1-7 days
 Contact Resistance50 mΩ max
Insulation Resistance1000MΩ Min
Operating Temperature-20°C ~+55°C
Wire SolderingAcceptable and with fast shipping
AccessoriesNut, Rubber Gasket
More size7MM 8MM 12MM 16MM 19MM 22MM 25MM 28MM 30MM 44MM
Customized requirement Acceptable
A small box10 box
The number of lifeOver 50000 times
The box size20.5cm*14cm *7cm
Large box size22cm *28.5cm *30.5cm
Single  weight:

0.02 kg
